Item NO.:
ES-10240Product Origin:
ChinaColor:
BlackFeatures
LCD displays clear battery information in real time
Low internal resistance delivers high current on demand
SBM improves battery life and reduces generated heat
Compact design with 10-15 year operating life
|
Model |
ES-10240 |
|
Nominal voltage |
51.2V |
|
Connection type |
15S1P |
|
Rated capacity |
Typical：200Ah |
|
Minimum：195Ah |
|
|
Maximum continuous discharge current |
≤100A |
|
Rated discharge current |
≤100A |
|
Rated charge current |
≤60A |
|
Communication |
SST19-247B-REV1.2 |
|
Operation temperature range |
Charge：0 ~ 55℃ |
|
Discharge：—20 ~ 55℃ |
|
|
Internal impedance |
＜100mΩ |
|
Charging mode |
C.C/C.V. |
|
Charging voltage |
54.75V |
|
Voltage at end of discharge |
40V |
|
Overcharge voltage |
3.65±0.05V (Adjustable) |
|
Over discharge cut off voltage |
2.5±0.01V (Adjustable) |
|
Over current |
Discharge overcurrent value: ≥105A |
|
Dimensions |
483*440*267mm |
|
Weight |
85kg |
